Cable Tester
Product Details:
- Power 100 Watt (w)
- Product Type Cable Tester
- Dimension (L*W*H) 400 x 350 x 145 Millimeter (mm)
- Color Voilet
- Machine Speed 50-300 RPM
- Application Industrial
- Weight 7-10 Kilograms (kg)
- Click to View more
X
Cable Tester Price And Quantity
- 1 Unit
Cable Tester Product Specifications
- 50-300 RPM
- Voilet
- 400 x 350 x 145 Millimeter (mm)
- Cable Tester
- 100 Watt (w)
- 7-10 Kilograms (kg)
- Industrial
Cable Tester Trade Information
- 100 Unit Per Month
- 10 Days
Product Description
In order to cater to the diversified requirements of our valued patrons, we have been manufacturing and exporting the best quality Cable Tester. These testers are manufactured using high-grade material that is sourced reputed vendors of the market. For manufacturing these equipment, we have developed the state-of-the-art manufacturing plant where various hi-tech machines have been installed. Additionally, we make sure that this Cable Tester is made available to the clients within the stipulated time frame and that too at most competitive price.
Features:
- Easy operations
- Low maintenance
- Optimum performance
- Longer service life
Technical Specifications:
|
Model |
CAW-8080A |
|
Test Points |
128, 256, 384, 512 |
|
Continuity R. |
100, 500, 1K, 5K, 10K, 50K |
|
Insulation R. |
500K, 1M, 2M, 5M, 7M, 10M, 20M |
|
Test Voltage |
15Vdc |
|
Test Current |
15mA (MAX.) |
|
Test Speed |
40960P-P/sec |
|
Standard Interface |
Printer Port |
|
Option Interface |
PLC.PC-Link |
|
Fixture Interface |
64 Pin Flat Cable |
|
Display |
2 Lines x 20 Character |
|
Step Test Function |
Yes, (Max, 99 Step) |
|
Bare-end Test |
Yes, A port 64Pin |
|
Sequential Test |
Yes |
|
Search Function |
Yes |
|
Intermittance Test |
Yes, Faster |
|
Open-Side |
Yes, Show a or b lower Case |
|
Fixture Short Test |
Yes, Auto-Test When power On |
|
Intermittance Lock |
Lock / Unlock |
|
Error Message |
All error, or 1-8 set |
|
Fault Results |
Display automatically |
|
Delay Time Setting |
Yes, 1-50 Counter |
|
Volume Adjustable |
8 Steps Volumes, Individual Pass |
|
No. OF KEY |
16 Key |
|
Power |
100-260 VAC 50/60Hz |
|
Operating Temp |
10C40c |
|
Dimension |
400 x 350 x 145mm ( 1.99' ) |
|
Weight |
N.W.: 7kgs G.W.: 10kgs |
